HemoLens 16 - true 100x oil scanner
Hemolens - 100x Oil

10x faster screening with High Density Information
Instant Cell Sorting with integrated on-premise GPUs
Thank you! Our team will share the quotation shortly.
Oops! Something went wrong while submitting the form.
Loading...
W B C
R B C
P L T
WSI for PS / BMA
100x Z stacks
Cell Differential AI
The All-Digital Workflow
1
Walk-away Scanning by the technician
Auto monolayer / feather-edge detection.
Auto Oil dispensing.
Auto-cell detection + Multi-objective scanning.
2
AI-enabled Cell Differentiation
120 WBCs are classified, sorted & flagged.
No cloud upload needed. AI runs on the local GPU.
3
Tele-reported
by Specialists
Secure remote review by the Pathologist.
Abnormal cells are pre-flagged and sorted.
Resulting in 10x faster reporting.

The All-digital Workflow

Remote work is something beautiful & AI makes it 10x faster

Step 1
Walk-away Scanning by the Lab Tech

- Auto monolayer / feather-edge
- Auto Oil dispensing

Step 2
Instant AI does Cell Sorting

- 120+ WBCs are bucketed & flagged
- Local GPU does an instant job without any cloud uploads

Step 3
Tele-reported by Specialist

- Pathologist remotely reviews the sorted cell images
Walk-away Scanning by the technician
- Auto monolayer / feather-edge
- Auto Oil dispensing
Instant AI does Cell Sorting
- 120+ WBCs are bucketed & flagged
- Local GPU does an instant job without any cloud uploads
Tele-reported by Specialist
- Pathologist remotely reviews the sorted cell images
Technical Specifications
Slide Capacity
16 slide capacity supporting
a.  Slides with / without coverslips
b.  Slide thickness from 0.8 to 2mm
c. Slide shape 1"x3"
Optical Setup
Robotic turret with 2 Objectives
a.  100x oil immersion
b.  40x dry
High power flash LED & Condenser optimized for multiple NAs
Image Resolution
Large size 2nd gen sony sensors yield
a.  0.08 microns / pixel @ 100x
b.  0.22 microns / pixel @ 40x
Secondary Preview Camera for single shot quick view of slide
Scan Algorithm
Steps within Auto-scan
Single shot capture with Preview camera
WSI @ 40x for AI determined boxed area
Switch to 100x & Auto Oil dispensing
100x scan for AI-determined ROIs
Scan Time
Time for specific scanning modes
a.  3.5 mins for 40x Monolayer + 100x 120 ROIs
b.  6 mins for 40x (20x20mm) + 100x 120 ROIs
c.  15 mins for 100x (15x15mm)
d. 75 seconds for 40x (15x15mm)
Physical Properties
A tabletop device  with
Width   :  21 Inches
Depth   :  19.5 Inches
Height  :  24 Inches
Weight :  55 Kg (121 lb)

Designed for Maximum Utility with Minimal AI

Accurate pre-bucketed WBCs across classes for quick flagging
Proven to speedup the review process by 10x
Pick specific etiologies from RBC morphometric parameters
Filter based on diameters to hunt for microcytic and macrocytic anemias
Sort cells based on elongation to quickly detect sickle cells
Surface irregularity based sorting to check for Poikilocytosis
Hunt for abnormal Platelets based on filtering & sorting across morphometric parameters
Platelet sorting to check for myeloproliferative or myelodysplastic syndromes
Order platelets by size to hunt for macrothrombocytopenia
Try the fully featured software online first hand
request access

Solved for PHI

Want to know more?
Speak to AN expert
AI without Cloud Uploads
HemoLens is equipped with powerful enough GPUs to run all the AI based image analysis software locally and hence never uploads data to cloud.

Hence, scanned images / patient data doesn't leave Hospital / Lab's network
Secure Remote Access
For tele-reporting purpose a VPN (Virtual Private Network) is setup allowing encrypted data to reach directly to the personal computer of the reporting pathologist.

Explicit network firewalls are setup to avoid unauthorised communication over the internet.
Get it all..
Without burning a hole in your pocket
Dr. Chandra Krishnan from Clinical Pathology Associates
Dr. Imran Khan - Digital Pathology User with research workflows
"Morphle’s greatest strengths v/s other microscope slide scanner solutions is its simplicity and ease of customisation that lets researchers create a perfect digital pathology workflow for their unique studies."
"Morphle’s greatest strengths v/s other microscope slide scanner solutions is its simplicity and ease of customisation that lets researchers create a perfect digital pathology workflow for their unique studies."
Dr. Imran was looking for a whole slide-scanning solution that would give him control over his study.
With tools that gave him a black box solution and just a number always swayed him out of his comfort zone. During our initial discussion, Dr. Imran wanted a pathology slide scanner that had the perfect resolution to help him hunt for metastatic colonies from xenograft tumor models. On this, an option to export the annotations as a CSV was all that he needed.
Further discussion post installations, we tried to understand how we could help him further and built a solution that would let him hunt for metastasis and help out accurately annotate a bounding box around the micro-tumours.
Dr. Chandra Krishnan from Clinical Pathology Associates
Dr. Ahmed Ali - Digital Pathology for education
"When it comes to tele-education, Morphle is my #1 go-to tool. If you’re serious about Digital Pathology, get hold of Morphle.”
"When it comes to tele-education, Morphle is my #1 go-to tool. If you’re serious about Digital Pathology, get hold of Morphle."
Dr. Ahmed is someone who likes spending his free time teaching students across the globe and sharing his acquired expertise. He was seeking a partner to help him jump the barriers of network connectivity and the security risks of hosting slides.
Owing to Morphle's unlimited concurrent logins and web-based viewer that is simple and intuitive, Dr. Ahmed can share a link to his Digital Pathology scans locally hosted and focus on what matters most, Educating the budding pathos!
His relentless pursuit of knowledge under the microscope has led to countless quality diagnoses all across the globe.
Dr. Chandra Krishnan from Clinical Pathology Associates
Dr. Hav - Digital Pathology for cross-border reporting
"Morphle’s tele-pathology setup has huge potential to improve access to diagnostic services for underserved geographies."
“Morphle’s tele-pathology setup has huge potential to improve access to diagnostic services for underserved geographies.”
Microscope slide scanners have helped me deliver quality pathology expertise to my patients - all the way in Southeast Asia.
Every day, Digital Pathology helps me to report cases from the mobile device in my hand - in the comfort of my study.

The flexibility and productivity boost via Digital Pathology has been a huge benefit. Without the operational hassles of coordinating across countries and time zones, I can now focus on what truly matters -  using my skills for timely diagnosis, irrespective of where I am.
Dr. Chandra Krishnan from Clinical Pathology Associates
Dr. Jayaram - Driving Digital Pathology for high throughput reporting
I was impressed by how Morphle microscope slide scanners managed to solve even not-so-obvious issues of digital pathology - viewer lags, fragmented LIS integration, and bloated data storage. It manages to tackle minor yet critical issues such as scanning fresh slides with wet coverslips for urgent reporting.”
"I was impressed by how Morphle microscope slide scanners managed to solve even not-so-obvious issues of digital pathology - viewer lags, fragmented LIS integration, and bloated data storage. It manages to tackle minor yet critical issues such as scanning fresh slides with wet coverslips for urgent reporting."
It’s a complete and carefully designed solution - even for advanced use cases. Comprehensive report generation with labeled images and efficient data management has helped us consolidate the multi-pathologist workflow in our clinical practice to make it truly digital.
An added bonus has been saving on the network storage cost -  nearly 4X, thanks to Morphle Digital Pathology’s compact Whole Slide Scanning data format.
Dr. Chandra Krishnan from Clinical Pathology Associates
Dr. Alireza - Realizing Digital Pathology for business impact
With Morphle, we finally have a whole slide scanner that works well with Bone Marrow Aspirates. We are switching our entire tele-reporting caseload to Morphle scanners.”
"With Morphle, we finally have a whole slide scanner that works well with Bone Marrow Aspirates. We are switching our entire tele-reporting caseload to Morphle scanners."
Before Morphle, for BMAs, we had a sub-standard scanning workflow. Morphle delivered a unique solution to our problem with effective whole-slide scanning for BMAs. Additionally, the cell locating interface was a plus helping pathology assistants screen faster. We are now on track with our tele-microscopy goals.
Dr. Chandra Krishnan from Clinical Pathology Associates
Dr. Ingerlisa Mattoch Digitizing a solo Dermatopathology Practice
"The Morphle team has been exceptional in helping me install, optimize, and incorporate my scanner into our workflow. We have the MorphoLens 6 in house. As background on my role, I am a sole Dermatopathologist and serve numerous large dermatology practices and other private practitioners in northern Colorado. I review approx. 120-150 slides per day (99% Dermpath)."
"The team has been exceptional in helping me install and incorporate my scanner into our workflow. The digital slides are of superior resolution and scanning time is also short. On average, we can scan 6 sets of slides in 8-10 minutes.
I have worked on many Digital Pathology platforms & the scans from Morphle are by far the best from a resolution and quality perspective."
The digital slides - not only are they of superior resolution, but the scanning time is also as short as possible. Working together with my histology team, and the development team at Morphle, we have developed a protocol that allows for routine skin biopsies, such as primary punch and shave biopsies, to be scanned in ~1 minute each. Excision sections (larger tissue) scan at about 2 minutes per slide. On average, we can scan 6 sets of slides in 8-10 minutes. The process for loading and scanning the slides is extremely intuitive and training my staff has been quite easy. In terms of interpreting cases, using the MorphoLens 6 scanned images, I find my sign-out to be extremely robust. As background, I have worked on a number of digital Pathology platforms. The MorphoLens 6 slide scans are by far the best I have worked with from a resolution and quality perspective. This system is also the easiest to manipulate from an end-user perspective for zooming, rotating, annotating, etc.
5 Million+ slides reported on Morphle whole slide scanners and counting!
